Body is made of sheet steel with electrostatic powder coating. Impeller is made of Glass-reinforced Polyamide, or cast aluminum alloy. The motors are IP55 class, 4 and 6-pole motors. Efficiency class IE3 and Class F insulated.
Airflow direction is from impeller to motor. Variable pitch angle for achieving optimum flow conditions. Can be installed vertically and horizontally according to the usage.
The device is capable of exhaust air at maximum temperature 60 ºC.
Available in long casing (LC), Short Casing (SC). The fan blades are manufactured in airfoil profile to achieve high aerodynamic efficiency. The Impeller of the fan is balanced dynamically based on ISO 14694 standard.
It works with low noise levels and is designed to be maintenance-free for long periods of time.
It is used for ventilation of high-volume factory, warehouse and hangars. It provides the ideal solution for large areas with its high flow rates and static pressures.
Available 10 standard sizes from 450 mm to 1250 mm, Custom made sizes can be manufactured upon customer's request.
